Model Number : HPIXP-1024

Certification : CE、MSDS

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : L/C,D/A,D/P,T/T

Supply Ability : 1000 pcs per mouth

Delivery Time : 5-8 weeks

Packaging Details : 790×325×402mm（Battery Pack）

Communication Protocol : CAN/WiFi

Battery Pack Net Weight : 44kg

Protection Class : IP54

Cooling Method : Natural Cooling

Cycle Life : 6,000 cycles

Standard Power : 10000W

Maximum Voltage : 1000VDC

Storage Temperature : -20～55℃

Contact Now

Home Energy Storage Integrated Machine Series 10.24~20.48kwh IP54 HPIXP-1024 CAN/WiFi

Product parameter

Model	HPIXP - 1024	HPIXP - 1536	HPIXP - 2048
Single - cell Package Energy	5.12kWh
Nominal Voltage	102.4V
Product Dimensions	700×235×307mm
Packaging Dimensions	790×325×402mm
Product Net Weight	44kg
Overall Dimensions	700×235×1470mm	700×235×1772mm	700×235×2075mm
Total Net Weight	132kg	177kg	222kg
Total Voltage	204.8V	307.2V	409.6V
Rated Energy	10.24kWh	15.36kWh	20.48kWh
Operating Voltage	172.8～230.4V	259.2～345.6V	345.6～460.8V
Operating Temperature	0～55℃
Storage Temperature	-20～55℃
IP Rating	IP54
Cooling Method	Natural Cooling
Communication Protocol	CAN/WiFi
PV Input Parameters
Maximum Power	15000W
Maximum Voltage	1000VDC
MPPT Voltage Range	200 - 850VDC
Single - string Maximum Current	13A/13A
AC Output/Input Parameters
Standard Power	10000W
Maximum Output/Input Current	17A/25A
Standard Frequency/Voltage	50/60Hz;400/380VAC
